Material BN 73
μi (reference)
2500
Anfangs-Permeablität
Max. Permeablität
4000
Frequenz Resonanz
0.001-1 MHz
Frequenz Breitband
0.5-30 MHz
Frequenz Drossel
10-50 MHz
Kernmaterial
Ni/Zn
Ferrite Material Constants
Specific Heat
0.25 cal/g/°C
Thermal Conductivity
3.5 - 4.5 mW/cm-°C
Coefficient of Linear Expansion
8 - 10x10-6/°C
Tensile Strength
4.9 kgf/mm2
Compressive Strength
42 kgf/mm2
Young's Modulus
15x103 kgf/mm2
Hardness (Knoop)
650
Specific Gravity
≈4.7 g/cm3
Die oben genannten Eigenschaften sind typisch für Amidon MnZn- und NiZn-Ferrite.
The above quoted properties are typical for Amidon MnZn and NiZn ferrites.
